G-TEC 18.5-08-500
Workstation complete with tank and dryer with line filters

DNAir2 controller
Air dryer + filters
Thermostatic valve

Lubricated screw compressor with belt transmission, DNAir2 electronic controller. Cabin with radial ventilation and integrated refrigerated dryer complete with prefilter and microfilter. 500 litre tank

plus fini
Read more
lubrificazione power system
Lubrication
Lubricated
aria-resa power system
Air outflow
2700 l/min.
pressione-max power system
Max. pressure
8bar / 116psi
potenza power system
Power
18,5 kW
G-TEC 18.5-08-500 Workstation complete with tank and dryer with line filters

Technical data

G-TEC 18.5-08-500
Product code
V83SU92PWSB80
Lubrication
Lubricated
Air-end
FS50
Air receiver (l)
500
Power (kW)
18,5
Air outflow
l/min.
m3/min.
c.f.m.
2700
2,7
95
Max. pressure
bar
p.s.i.
8
116
Nr. of stages
1
Sound level (dB(A))
*
70
Voltage / Frequency (Volt / Hz)
400/50
Connection (G)
3/4"
Controller
DNAir2
Type motor
Electric
Energy efficiency
IE3
Gross weight (kg)
600
Net weight (kg)
567
Packaging dimensions LxWxH (mm)
2070x800x1930
Net Dimensions LxWxH (mm)
1980x730x1750
*Sound pressure level measurement carried out at a distance of 7 metres.

Download

catalogo powersystem
Catalogue
download powersystem download powersystem
dati tecnici powersystem
Technical data
download powersystem download powersystem
