HD60CV3/150 CT3
Professional single-stage belt-driven compressor with high-efficiency 'V' pump unit.

3 cylinders
With wheels
Three-phase

Single-stage belt driven compressor designed for intensive use with a wide range of pneumatic tools. Equipped with a 3 hp pumping unit with highly efficient cast iron cylinders. The 150-litre tank for a large air reserve with comfortable full handle, double wheels and fixed foot guarantee greater stability and agile movements.

plus fini
Read more
lubrificazione power system
Lubrication
Lubricated
serbatoio power system
Air receiver
150 l
pressione-max power system
Max. pressure
10 bar
potenza power system
Power
3 Hp
rumorosita power system
Sound level
Medium
allestimento power system
Equipment
With wheels
*The images are for illustrative purposes only
HD60CV3/150 CT3 Professional single-stage belt-driven compressor with high-efficiency 'V' pump unit.

Technical data

HD60CV3/150 CT3
Product code
RWHC541PWS045
Lubrication
Lubricated
Compressor pump
HD60CV3
Air receiver (l)
150
Power
Hp
kW
3
2,2
Max. pressure
bar
p.s.i.
10
145
Nr. of cylinders
3
Air displacement
l/min.
c.f.m.
440
15,5
R.P.M.
1200
Voltage / Frequency (Volt / Hz)
400/50
Type motor
Electric
Gross weight
kg
lb
107
235,9
Packaging dimensions LxWxH (mm)
1310x430x1030
EAN code
8016738759143

Download

catalogo powersystem
Catalogue
download powersystem download powersystem
dati tecnici powersystem
Technical data
download powersystem download powersystem
